7. Hydration debugger

Your tester refreshes the page and the count flips from 12 to 0. Server-rendered HTML said one number; the client booted up and said another. They send you a screenshot of the half-second of flicker — the SSR'd value visible until the React reconciler stamps over it with the wrong one.

That's a hydration mismatch, and the Hydration panel is the focused view. The Issues ribbon will already have a :rf.error/hydration-mismatch row; click into it and the panel paints both render trees side-by-side with the offending node highlighted. The diagnosis isn't "the trees don't agree" — it's "the view at cart.views:cart-total:73 rendered $12.00 on the server and $0.00 on the client, because the cofx that seeds :cart/items read (js/Date.) in a way the JVM-side renderer couldn't."

The panel only appears in the sidebar when hydration actually runs in the page. A SPA-only build won't see it at all. SSR ships at Guide 11.

What it shows

Two columns side-by-side: the server render tree and the client render tree. The mismatch is highlighted — a node that exists on one side and not the other, an attribute that differs, a textual delta. Click any mismatched node to inspect the diff in detail.

Below, a mismatch reason chip — the runtime classifies hydration mismatches into a fixed taxonomy:

Reason	Meaning
:rf.hydrate/missing-handler	The server app-db references an id not registered on the client.
:rf.hydrate/schema-mismatch	The hydrated app-db doesn't validate against a client-registered schema.
:rf.hydrate/dom-divergence	The two render trees differ structurally.
:rf.hydrate/attribute-drift	Same DOM, different attribute values (commonly data-*, key, dates).

The classification is the wire-level signal that an APM bridge would also see. Causa is the human-friendly renderer of the same fact.

What hydration is, briefly

re-frame2's SSR adapter renders the same views to HTML on the JVM. Per request, the runtime allocates a frame, runs the cascade, serialises the resulting app-db into the response (transit, embedded in a <script>), and ships the HTML.

In the browser, the client init! reads the embedded app-db, dispatches :rf/hydrate, and runs the same views. The expectation is that the two trees agree — same app-db, same handlers, same view code, same output.

When they don't, it's almost always one of:

• An event handler that read (js/Date.) or (rand) somewhere it shouldn't have.
• A view that called js/window from inside the body (no SSR-shape guard).
• A cofx that returned different data on the server (the request-id wasn't seeded the same way).

The panel surfaces which view mismatched, which attribute, with what values — at the resolution of a single line of source. That's why the opener's diagnosis sentence reads as one specific call-out rather than the generic "the trees don't agree."

The fix loop

1. Note the mismatch reason chip. Most chips name the diagnosis.
2. Click the offending node — read the server value and the client value side-by-side.
3. The click-to-source affordance applies; jump to the view's source.
4. Fix the divergence (push the non-deterministic call out of the view body, into an event handler or a cofx).
5. Reload. The panel goes green.

The runtime emits a :rf.error/hydration-mismatch trace event for every detected mismatch, so the Issues ribbon also surfaces them — Hydration is the focused view; Issues is the unified view.

What this panel isn't

It's not a server-side renderer profiler. SSR performance is JVM-side; Chrome DevTools can't see it. Use the JVM host's profilers for that.

It's not a hydration prevention — re-frame2 doesn't try to stop you from writing a view that mismatches. The Boundary contract is "writers honour the schema; consumers validate." Causa is on the validation side.

For when not to hydrate at all — view components that should opt out of SSR entirely — see the SSR chapter's coverage of the :client-only? view metadata. The panel respects that flag; opted-out views don't show up as mismatches.

Next: the machine inspector.
