3. Recorder + Test Codegen

This is the hero chapter. Storybook 9's headline feature is the interaction-test recorder — record clicks and form fills on a canvas; out comes a play body. Story's incarnation is cleaner: the captured body is EDN, not TypeScript; the same map shape Story already uses for hand-authored :play slots.

What it does, in one minute

1. Open a variant in Canvas mode.
2. Click record on the canvas toolbar. The shell starts capturing.
3. Interact with the component — click buttons, type into inputs, submit, hover. Causa's trace bus is the substrate; every dispatch lands in the recorder's buffer.
4. Click stop.
5. A modal opens. Inside, the generated :play body:

   {:play [[:counter/initialise 0]
           [:counter/increment]
           [:counter/increment]
           [:rf.assert/path-equals [:count] 2]]}


6. Copy, paste into your stories namespace, save. The recorded interaction is now a canonical test.

That's the whole gesture. The recorder doesn't capture mouse coordinates or DOM-level events; it captures the re-frame2 events your interactions produced plus the resulting assertions. The output is portable, readable, and parses by every other tool that consumes Story variants.

How the capture works

Story's recorder registers a :rf.story.recorder/* listener on the trace bus while recording. Every dispatched event that originated from canvas interaction (as distinct from setup events the variant's own :events slot fires) is captured into the buffer.

The recorder distinguishes capture-source events from setup events through the trace event's :dispatch-source tag — a runtime stamp on every dispatch identifying its provenance. Setup-phase events carry :rf.story/source :variant-events; canvas-interaction events carry :rf.story/source :user. The recorder filters on :user only.

When recording stops, the buffer is shape-mapped into the canonical :play form:

• Pure dispatches become bare event vectors.
• Dispatches that produced asserter-relevant app-db changes are followed by inferred :rf.assert/path-equals rows. (You can disable inference per-recording.)
• Long click sequences against the same target are coalesced when adjacent.

The output is human-readable. Storybook 9's TypeScript recorder produces await canvas.getByRole('button').click(); await expect(...).toHaveTextContent('2'); — Story's recorder produces three EDN tuples. The EDN survives serialisation; the TypeScript surface doesn't.

Inference and friction

The recorder is opinionated about what's worth keeping:

• Idle settle — sequences that the runtime quiesces between are recorded as one settle boundary, not a flood of fine-grained events.
• Sensitive-flagged events — events whose handler is metadata-tagged :sensitive? true are recorded with elided payload (a :rf/redacted marker in their place). The privacy contract from Guide 23a applies to the recorder too.
• Multi-click coalescing — clicking +1 five times produces five [:counter/increment] rows. Stable. Predictable. (No "5 × [:counter/increment]" coalescing — it'd break diff readability when the recording later needs editing.)

You can edit the recording before pasting. The modal's left pane is the EDN; the right pane is a preview run against a throwaway frame, so you see what the play would do before committing it.

Why EDN-first matters

Three things you get for free:

• Round-trips through MCP. An agent host can call recorder/start, recorder/stop, get the EDN body back, hand it to register-variant. The end-to-end is generate a test from interaction without leaving the agent's tool catalogue. Storybook 9's TypeScript output requires the agent to either run TS, or hand-translate.
• Visual-regression diffs are stable. The play body is data — sorted, formatted, comparable. Diff-ing two recordings of the same scenario after a refactor surfaces what changed in the interaction, not what changed in the formatting.
• The "save current canvas state" affordance falls out for free. Tweak the controls on an existing variant, click save as new variant… at the bottom of the controls panel, and Story emits a (reg-variant ...) form pinned to the current selection — args, mode overrides, cell-local edits collapsed into one snapshot. Same modal, same EDN-paste flow.

  ;; Click 'save as new variant…' after dragging :n up to 7 in a :dark mode →
  (story/reg-variant :story.counter/saved-739221
    {:extends :story.counter/happy-path
     :args    {:label "Counter" :n 7 :theme :dark}})


When the recorder isn't the right tool

Three escape routes:

• A multi-step setup the user wouldn't do interactively. Reach for the variant's :events slot directly — pure setup belongs there, with the play sequence describing only the interactive segment.
• An assertion the inferred ones don't cover. The recorder infers :rf.assert/path-equals; for :rf.assert/sub-equals, :rf.assert/state-is, or any of the other five canonical assertions, edit the captured EDN. The pre-paste preview confirms the edit works.
• A test that crosses frame boundaries. Recorder captures one variant's frame. Cross-frame assertions belong in cljs.test against the result map from run-variant.

The recorder is for the common case: I just clicked through this; please remember what I did. The escape hatches are there for the harder cases without polluting the common path.

MCP write surface

The agent-facing surface is the same gesture in reverse. An agent host calls register-variant with an EDN body; Story validates against the schema; the variant lands in the registry; the canvas can render it. Combined with the recorder's stop emission, an agent can run the loop:

1. Generate a candidate variant body (from a prose description, from a screenshot, from a code-read).
2. Register it.
3. Watch the variant render in the canvas.
4. Read failures (read-failures).
5. Refine and re-register.

That's the agent self-healing loop. It's the reason variant bodies are EDN to begin with.

The agent surface lives at tools/story-mcp/ — a stdio JSON-RPC server exposing nineteen tools across Dev / Docs / Testing / Write categories. The Write surface is gated behind --allow-writes at startup. The contract is in tools/story-mcp/README.md.

Next: workspaces + args editor.
