7. Multi-substrate side-by-side

re-frame2 ships with four view-substrate adapters: Reagent, Reagent-slim, UIx, and Helix. Most apps pick one and stay there. But for component-library maintainers and adapter authors, the same variant rendered under multiple substrates is the daily diff.

Story's :substrates slot on reg-story declares which substrates the parent story exercises:

(story/reg-story :story.counter
  {:component  :counter-with-stories.views/counter-card
   :substrates #{:reagent :uix :helix}
   :args       {:label "Count"}})

Now every variant under :story.counter mounts under all three substrates, side-by-side, in a tri-cell layout.

What you see

Three columns. Same variant. Three substrates rendering it. The component must be substrate-agnostic — keyword view-id, registered through reg-view, no substrate-specific imports in the view body. The runtime knows how to invoke the keyword under each substrate.

Same variant rendered side-by-side under Reagent, UIx, and Helix

If a substrate-specific behaviour diverges (e.g., Reagent's r-atom mount semantics vs UIx's signal mount), the three columns diverge visibly. That's the point of the side-by-side: visual confirmation of behaviour parity.

The contract on substrate-agnostic views

For :substrates to work, your view registration must be substrate-agnostic. Concretely:

  • No :require of substrate-specific libraries from inside the view body. (reagent.core, uix.core, helix.dom — none of them.)
  • Use reg-view (not Reagent's defn shape or UIx's defui shape directly). reg-view is the substrate-agnostic registration macro; the adapters interpret the registered body.
  • For host-specific affordances (Reagent's :> shape, UIx's $ shape), guard them behind a (case (rf/substrate) :reagent ... :uix ...) switch. Most apps don't need this.

Views that do need substrate-specific code aren't covered by :substrates; they live under a single-substrate parent story. The adapter chapters at Guide 19 — Adapters walk the gotchas.

What the side-by-side diff is for

Three audiences reach for this:

  • Adapter authors. When you're writing a new adapter (or fixing a regression in an existing one), you compare the same variant under your new adapter and the canonical Reagent. Visual divergence = bug in the new adapter. The diff is per-variant, per-arg-tuple, per-mode — a tiny budget for differences.
  • Component-library maintainers. A re-frame2 component library that ships across substrates lives or dies on whether :re-com/dropdown renders the same way under all four. Side-by-side is the regression test.
  • Apps migrating substrates. When a project moves from Reagent v1 to Reagent v2, or from Reagent to Reagent-slim for bundle-size reasons, side-by-side variants are the safety net.

For most app code, you don't need this. You pick a substrate at init! time and your stories run under that substrate. Multi-substrate is for the cases where multi-substrate is the point.

What's deferred

Two surfaces aren't in v1.0:

  • Per-substrate args. You can't currently say "use these args under Reagent and those args under UIx" — args are substrate-agnostic. If the substrates need different args to produce the same output, the registered view is doing something host-specific that probably should be factored out.
  • Cross-substrate snapshot identity. Today every substrate produces its own snapshot identity (because the rendered DOM is hashed). A future :semantic-fingerprint slot would let visual-regression diff intended output rather than rendered output. The spec rev is open; today the right tool is human visual review.

That's Story.

You've seen:

  • The three load-bearing rules: frame-per-variant, EDN bodies, record-don't-throw.
  • The four daily affordances: variants, mode tabs, recorder, workspaces.
  • The three surfaces unusual for the Storybook lineage: snapshot identity, time-travel, multi-substrate.
  • The agent surface (story-mcp) that consumes all of the above through MCP tools.

If you want to look at the worked example end-to-end, tools/story/testbeds/counter_with_stories/ wires the seven reg-* macros against the canonical counter app — four variants, two workspaces, every assertion shape, every decorator kind, plus a passing integration test.

Or open #/stories against your own app, register one variant, and see how it feels.
